Dodge Dakota (1989-1994) pnk data link connector Wiring diagram
This page shows the only wiring diagram for the component.pnk data link connector, which is found in the car Dodge Dakota (1989-1994). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pnk data link connector (1 of 1)
2.5L ONLY
B/H CONN
BLK/TAN WIRE
DATA LINK TRANSMIT DATA LINK RECEIVE
DK BLU WIRE
ENGINE CONTROL SYSTEM (HEATED OXYGEN SENSOR)
HOT AT ALL TIMES
IGNITION SWITCH (ON STEERING COLUMN)
LOCK
LT GRN WIRE
PNK DATA LINK CONNECTOR WIRE
PNK WIRE
POWER DISTRIBUTION SYSTEM
POWER GROUND POWER GROUND
POWERTRAIN CONTROL MODULE (RIGHT FENDER SIDE SHIELD)
RUN WIRE
Go to component -> Computer data lines -> PNK DATA LINK CONNECTOR WIRE
