Dodge Challenger III facelift (2010-2014) Tire pressure monitoring circuit

1 2 3 4 FUSED B(+) GND CAN C BUS (+) CAN C BUS (-) BLK/WHT WIRE COMPUTER DATA LINES SYSTEM HOT AT ALL TIMES POWER DISTRIBUTION CENTER (RIGHT REAR OF TRUNK) FUSE 30 RED WIRE RED/GRY WIRE RED/YEL WIRE TIRE PRESSURE MODULE (RIGHT REAR WHEEL WELL) WHT/BLK WIRE WHT/LT BLU WIRE
