Interior lights circuit for Dodge Challenger III (2008-2010)

BLK WIRE BLK/ORG WIRE BLK/TAN WIRE CAN B CARGO LAMP CIRCUIT BREAKER 1 CLUSTER COMPUTER DATA LINES SYSTEM COURTESY LMPS DRIVER DECKLID DOOR LATCH (4 DOOR SEDAN) (DECK LID LATCH) DECKLID RELEASE SWITCH DK GRN WIRE DK LID/LIFTGATE AJAR SW SENS DK LID/LIFTGATE RELEASE SW DRIVER PANEL LAMPS DRIVER SEAT BELT SWITCH DRV DR AJAR SW DRV SEAT BELT SW SNS FRONT READING LAMP FUSE 17 FUSE 29 FUSE 38 FUSE 40 FUSED B (+) GRY WIRE HDLP SW MUX RETURN HOT AT ALL TIMES HOT IN RUN OR START LAMP LEFT REAR FOOTWELL LAMP LEFT VANITY LT BLU WIRE LT GRN WIRE ORG/ WIRE ORG/BRN WIRE ORG/GRY WIRE ORG/RED WIRE PANEL LMPS DIMMER SIG PASS DR AJAR SW PNK WIRE PNK/GRY WIRE POWER DISTRIBUTION CENTER (RIGHT REAR OF TRUNK) READING/ RAIL LAMPS DRIVER RED WIRE RED/ORG WIRE RED/TAN WIRE RIGHT REAR FOOTWELL LAMP RIGHT VANITY TAN WIRE VIO WIRE VIO/ORG WIRE VIO/TAN WIRE VIO/WHT WIRE WHT WIRE WHT/ORG WIRE WHT/YEL WIRE YEL WIRE YEL/LT BLU WIRE YEL/WHT WIRE

BANK SWITCH BELOW GLOVE BOX) BLK WIRE BLK/LT GRN WIRE BLK/ORG WIRE BLK/WHT WIRE CUP PANEL HOLDER LPS LAMP DRV (PREMIUM) DRIVER DOOR LATCH DRIVER DOOR MODULE (MIDDLE OF DRIVER DOOR) DRV DR AJAR SWITCH GROUND GRY WIRE HDLP SWITCH MUX RETURN HEADLAMP SWITCH LEFT FRONT FOOTWELL LAMP (PREMIUM) LEFT HEATED SEAT SWITCH LT GRN WIRE ORG/ WIRE ORG/BRN WIRE ORG/GRY WIRE PANEL LAMPS DIMMER SIG PANEL LAMPS DRIVER PASS DR AJAR SWITCH PASSENGER DOOR LATCH PASSENGER DOOR MODULE (MIDDLE OF PASSENGER DOOR) RED/ORG WIRE RIGHT FRONT FOOTWELL LAMP (PREMIUM) RIGHT HEATED SEAT SWITCH RUN/ START RELAY SECONDARY DR AJAR SW SHIFTER LEVER ASSEMBLY PANEL LPS DRV VIO WIRE VIO/DK BLU WIRE VIO/TAN WIRE VIO/WHT WIRE W/ 4 SPEED W/ 5 SPEED M/T WHT WIRE WHT/YEL WIRE
