Dodge Challenger III (2008-2010) electronic overhead module (overhead console) Wiring diagrams
This page contains all the electrical diagrams for the component. electronic overhead module (overhead console), in which he is found in the car Dodge Challenger III (2008-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
electronic overhead module (overhead console) wiring diagram (1 of 2)
1 2 CAN B BUS (-) CAN B BUS (+)
12 13 CAN B BUS(-) CAN B BUS(+)
13 12 16 CAN B BUS (+) CAN B BUS (-) COM-LIN TPM LAN
17 16 CAN B BUS (-) CAN B BUS (+)
17 6 CAN B BUS (-) CAN B BUS (+)
2 1 CAN B BUS (-) CAN B BUS (+)
2 13 CAN B BUS (-) CAN B BUS (+)
4 14 CAN B BUS (-) CAN B BUS (+)
4 5 CAN B BUS (-) CAN B BUS (+)
5 6 CAN B BUS (+) CAN B BUS (-)
6 5 CAN B BUS (+) CAN B BUS (-)
BLK/TAN WIRE
CAN B BUS (+)
CAN C BUS (+)
CLUSTER
DATA LINK CONNECTOR (LEFT SIDE OF DASH, ABOVE PEDALS)
DIAGNOSTIC CAN C (+)
DRIVER DOOR MODULE (MIDDLE OF DRIVER DOOR)
ELECTRONIC OVERHEAD MODULE (OVERHEAD CONSOLE)
FRONT A/C HEATER MODULE
FUSE 8 CENTER (RIGHT REAR OF TRUNK)
FUSED B (+)
HANDS FREE MODULE (EXCEPT NAVIGATION) (RIGHT SIDE OF DASH)
HEATED SEATS MODULE (BELOW PASSENGER SEAT)
HOT AT ALL TIMES
LT BLU/RED WIRE
OF ENGINE COMPT) CAN C BUS (-)
PASSENGER DOOR MODULE (MIDDLE OF PASSENGER DOOR)
PASSIVE ENTRY MODULE (KEYLESS GO)
POWER DISTRIBUTION
RADIO
RADIO AMPLIFIER (LEFT OF DASH)
STEERING CONTROL MODULE (STEERING COLUMN)
SUNROOF MOTOR/MODULE (REAR CENTER OF HEADLINER)
TOTALLY INTEGRATED POWER MODULE (RIGHT SIDE ELECTRONICS
WHT WIRE
WHT/BLK WIRE
WHT/DK BLU WIRE
WHT/GRY WIRE
WHT/LT BLU WIRE
WHT/ORG WIRE
Go to component -> Computer data lines circuit (1 of 2) -> ELECTRONIC OVERHEAD MODULE (OVERHEAD CONSOLE)
electronic overhead module (overhead console) wiring diagram (2 of 2)
1 2 3 4 5 6 CAN B BUS (+) CAN B BUS (-) FUSED B(+) GND
16 17 CAN B BUS (+) CAN B BUS (-)
BLK WIRE
BLK/LT GRN WIRE
CAN B BUS (+)
CLUSTER
COMPUTER DATA LINES SYSTEM
DK GRN WIRE
ELECTRONIC OVERHEAD MODULE (OVERHEAD CONSOLE)
ELECTRONICS TOTALLY INTEGRATED POWER MODULE (RIGHT SIDE OF ENGINE COMPT)
EVIC DISPLAY
FUSE 38
HOMELINK BUTTONS
HOT AT ALL TIMES
LT GRN WIRE
POWER DISTRIBUTION CENTER (RIGHT REAR OF TRUNK)
RED WIRE
RED/DK GRN WIRE
W/O NAVIGATION W/ NAVIGATION
WHT WIRE
WHT/ORG WIRE
Go to component -> Overhead console circuit -> ELECTRONIC OVERHEAD MODULE (OVERHEAD CONSOLE)
