Dodge Caravan IV (2000-2007) temp sens in 1 2 3 4 Wiring diagram
This page shows the only wiring diagram for the component.temp sens in 1 2 3 4, which is found in the car Dodge Caravan IV (2000-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram temp sens in 1 2 3 4 (1 of 1)
1 2 3 4 GND SEAT SW IGN SW OUT FUSED B(+)
1 2 HTR (B+) HTR GND
4 5 3 IGN SW RUN DRIVER SEAT SW PASSEN SEAT SW
6 7 8 HTR GROUND HTR B(+) IGN SW OUT
BLK/ORG WIRE
BODY CONTROL MODULE (BEHIND LEFT SIDE OF DASH)
DK BLU WIRE
DK GRN WIRE
DRIVER HEATED SEAT CUSHION (IN DRIVER'S SEAT)
DRIVER HEATED SEAT MODULE (BELOW DRIVER'S SEAT)
FUSED B (+)
GND B+
GRY WIRE
GRY/PNK WIRE
HOT AT ALL TIMES POWER SEAT CIRCUIT BREAKER (UNDER DRIVER'S SEAT)
HTR B(+) HTR GND
HTR B(+) HTR GROUND
HTR GND B(+) GND GND
IGN SW RUN
INSTRUMENT PANEL SWITCH BANK
LT GRN/DK GRN WIRE
LT GRN/WHT WIRE
MEMORY SYSTEMS, POWER SEAT CIRCUIT
ORG/RED WIRE
PASSENGER HEATED SEAT CUSHION (IN PASSENGER'S SEAT)
PASSENGER HEATED SEAT MODULE (BELOW PASSENGER'S SEAT)
RED WIRE
SEAT SW GROUND
TEMP SENS IN
TEMP SENS IN 1 2 3 4
WHT/PNK WIRE
Go to component -> Heated seats circuit -> TEMP SENS IN 1 2 3 4
