Dodge Caravan IV (2000-2007) relay ctrl park lamp relay wiper on/off relay Wiring diagram
This page shows the only wiring diagram for the component.relay ctrl park lamp relay wiper on/off relay, which is found in the car Dodge Caravan IV (2000-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram relay ctrl park lamp relay wiper on/off relay (1 of 1)
AIR CONDITIONING SYSTEM DEFOGGER SYSTEM
ANTI-THEFT SYSTEM
BLK WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLK/YEL WIRE
EXTERIOR LIGHTS SYSTEM COMPUTER DATA LINES SYSTEM
FCM (UNLK/RUN/ST)
FRONT CONTROL MODULE
FUSE 14
GROUND B(+) HORN RELAY
HEADLIGHTS SYSTEM
HORNS SYSTEM
HORNS SYSTEM WIPER/WASHER SYSTEM
HOT AT ALL TIMES
IGNITION SWITCH (IN STEERING COLUMN)
INTEGRATED POWER MODULE (LEFT FRONT OF ENGINE COMPARTMENT)
LOCK UNLOCK
ORC (RUN) BLOWER MTR RELAY DEFOGGER RELAY
PNK WIRE
PNK/WHT WIRE
RELAY CTRL PARK LAMP RELAY WIPER ON/OFF RELAY
RUN WIRE
SEATS SYSTEM EXTERIOR LIGHTS SYSTEM
SHIFT INTERLOCK SYSTEM SUPPLEMENTAL RESTRAINTS SYSTEM
SUPPLEMENTAL RESTRAINTS SYSTEM
TRANSMISSIONS SYSTEM
WHT WIRE
WIPER/WASHER SYSTEM
YEL WIRE
Go to component -> Front controller circuit -> RELAY CTRL PARK LAMP RELAY WIPER ON/OFF RELAY
