Dodge Caravan IV (2000-2007) pnk 17 Wiring diagram
This page shows the only wiring diagram for the component.pnk 17, which is found in the car Dodge Caravan IV (2000-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pnk 17 (1 of 1)
AUTOMATIC HEADLAMP SWITCH SENSOR
BACKUP LAMP FEED
BLK WIRE
BODY CONTROL MODULE (BEHIND LEFT SIDE OF DASH)
DK BLU WIRE
FUSED IGNITION RUN/
FUSED IGNITION SWITCH OUTPUT (RUN)
GROUND
GRY WIRE
LEFT POWER MIRROR
LT BLU WIRE
MIRROR B+
ORG/ WIRE
OVERHEAD CONSOLE (EXCEPT BASE)
PNK 17 WIRE
PNK 6 WIRE
PNK WIRE
REAR VIEW MIRROR MIRROR B(-)
TAN WIRE
WHT WIRE
Go to component -> Automatic day/night mirror circuit -> PNK 17 WIRE
