Dodge Caravan IV (2000-2007) pci bus charging system ind ctrl voltmeter Wiring diagram
This page shows the only wiring diagram for the component.pci bus charging system ind ctrl voltmeter, which is found in the car Dodge Caravan IV (2000-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pci bus charging system ind ctrl voltmeter (1 of 1)
ASD RLY CTRL FUSED B(+)
AUTO SHUT DOWN RELAY
BATTERY
BATTERY TEMP SIG SENS GND PCI BUS
BLK WIRE
BRN WIRE
BRN/GRY WIRE
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK GRN WIRE
ENGINE CONTROLS SYSTEM
FRONT CONTROL MODULE PCI BUS
FUSE 16 FUSE 17
FUSE 24
FUSED B (+)
FUSIBLE LINK (10 GA-
GEN FLD ASD RLY OUT GND ASD RLY OUT
GENERATOR
GRY WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER
INTEGRATED POWER MODULE (LEFT FRONT OF ENGINE COMPT)
LT BLU WIRE
NCA WIRE
ORG/ WIRE
PCI BUS CHARGING SYSTEM IND CTRL VOLTMETER
POWERTRAIN CONTROL MODULE (LEFT REAR OF TRANSAXLE)
RED WIRE
STARTER MOTOR
VIO WIRE
W/ ABS
WHT WIRE
WHT/VIO WIRE
YEL WIRE
Go to component -> Charging circuit -> PCI BUS CHARGING SYSTEM IND CTRL VOLTMETER
