Dodge Caravan IV (2000-2007) org lt grn/ Wiring diagram
This page shows the only wiring diagram for the component.org lt grn/, which is found in the car Dodge Caravan IV (2000-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram org lt grn/ (1 of 1)
BLK WIRE
DK BLU WIRE
DK GRN/ LT GRN WIRE
DRIVER POWER SEAT FRONT RISER MOTOR (IN DRIVER'S SEAT)
DRIVER POWER SEAT HORIZONTAL MOTOR (IN DRIVER'S SEAT)
DRIVER POWER SEAT REAR RISER MOTOR (IN DRIVER'S SEAT)
DRIVER POWER SEAT RECLINER MOTOR (IN DRIVER'S SEAT)
DRIVER POWER SEAT SWITCH
HOT AT ALL TIMES
LT GRN GRY WIRE
LT GRN LT BLU WIRE
LT GRN ORG/ WIRE
LT GRN WHT/ WIRE
LT GRN WIRE
LT GRN YEL/ WIRE
LT GRN/ TAN WIRE
LT GRN/ VIO WIRE
ORG LT GRN/ WIRE
ORG/ WIRE
ORG/RED WIRE
PASSENGER POWER SEAT FRONT RISER MOTOR (IN PASSENGER'S SEAT)
PASSENGER POWER SEAT HORIZONTAL MOTOR (IN PASSENGER'S SEAT)
PASSENGER POWER SEAT REAR RISER MOTOR
PASSENGER POWER SEAT RECLINER MOTOR (IN PASSENGER'S SEAT)
PASSENGER POWER SEAT SWITCH
POWER SEAT CIRCUIT BREAKER (UNDER DRIVER'S SEAT)
RWD
VIO WIRE
Go to component -> Power seats circuit -> ORG LT GRN/ WIRE
