Dodge Caravan IV (2000-2007) oil pressure signal vehicle speed signal Wiring diagram

1 2 LINE 1 LINE 2 9 11 SEAT BELT SW SEAT BELT SW ABS AIR BAG WARNING IND BLK WIRE BLK/LT BLU WIRE BLK/LT GRN WIRE BLK/ORG WIRE BLU WIRE BRAKE FLUID LEVEL SWITCH BRAKE FLUID LEVEL SWITCH (ON BRAKE MASTER CYLINDER) BRAKE WARNING IND BRN WIRE BRN/RED WIRE BRN/TAN WIRE CHIME DRIVER CONTROLLER ANTI-LOCK BRAKE (RIGHT SIDE OF ENGINE COMPARTMENT) CRUISE IND DK BLU WIRE DK GRN WIRE DK GRN/ORG WIRE DK GRN/WHT WIRE DOOR AJAR IND DRIVER SEAT BELT SWITCH (AT SWITCH ON SEAT HARNESS) ECT SIG ECT SIGNAL ELECTRONIC PRNDL IND ENGINE COOLANT TEMPERATURE GAUGE ENGINE COOLANT TEMPERATURE SENSOR (LEFT SIDE OF ENGINE BLOCK) ENGINE OIL PRESSURE SWITCH (AT LEFT SIDE OF ENGINE, ON CYLINDER BLOCK) FRONT CONTROL MODULE WASHER FLUID LEVEL SWITCH FUEL GAUGE FUSE 24 FUSED B (+) GROUND GRY WIRE HOT AT ALL TIMES ILLUMINATION INSTRUMENT CLUSTER INTEGRATED POWER MODULE (LEFT FRONT OF LEFT TURN SIGNAL IND LIFTGATE AJAR IND LOW FUEL WARNING IND LOW COOLANT IND LOW WASHER FLUID LEVEL IND LT GRN WIRE LT GRN/GRY WIRE LT GRN/TAN WIRE OCCUPANT RESTRAINT CONTROLLER (BEHIND RIGHT SIDE OF DASH) ODOMETER OIL PRESSURE SIGNAL VEHICLE SPEED SIGNAL ORG/ WIRE ORG/WHT WIRE PANEL LAMPS DRIVER PARK BRAKE SWITCH (BEHIND LEFT SIDE OF DASH) PCI BUS POWERTRAIN CONTROL MODULE (LEFT REAR OF TRANSAXLE) RIGHT TURN SIGNAL IND SENTRY KEY IMMOBILIZER MODULE (AT STEERING COLUMN) SPEEDOMETER TACHOMETER TAN WIRE TRIP ODOMETER VEHICLE SPEED SENSOR (M/T) VEHICLE SPEED SIGNAL VIO WIRE VIO/BRN WIRE VIO/ORG WIRE VOLT IND WAKE UP SENSE WASHER FLUID LEVEL SW SNS WASHER FLUID LEVEL SWITCH (LEFT FRONT OF ENGINE COMPARTMENT) WHT WIRE WHT/LT GRN WIRE WHT/TAN WIRE WHT/VIO WIRE
