Dodge Caravan IV (2000-2007) memory seat/mirror/ adjustable pedals module driver power seat switch Wiring diagram
This page shows the only wiring diagram for the component.memory seat/mirror/ adjustable pedals module driver power seat switch, which is found in the car Dodge Caravan IV (2000-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram memory seat/mirror/ adjustable pedals module driver power seat switch (1 of 1)
A/C COMPRESSOR CLUTCH
A/C HEATER CONTROL
A/C- HEATER CONTROL FRONT BLOWER MODULE
A/T
ADJUSTABLE PEDALS SWITCH RIGHT POWER MIRROR
ANTI- LOCK BRAKE CONTROLLER
AUTO TEMP CONTROL
AUTOMATIC A/C
BATTERY
BLK WIRE
BRN WIRE
CD CHANGER
DATA LINK CONNECTOR (DLC)
DK BLU WIRE
DK GRN WIRE
DRIVER HEATED SEAT MODULE
DRIVER POWER SEAT SWITCH
DVD/CD CHANGER
EXCEPT HANDS FREE
FRONT CIGAR LIGHTER
FRONT CONTROL MODULE
GENERATOR
GRY WIRE
HANDS FREE
HANDS FREE MODULE
HEADLAMP SWITCH
HIGH NOTE HORN
INSTRUMENT CLUSTER HORN SWITCH
INSTRUMENT PANEL SWITCH BANK
LATE PRODUCTION
LEFT FOG LAMP
LEFT FRONT PARK/TURN SIGNAL LAMP
LEFT POWER MIRROR
LT BLU WIRE
LT GRN WIRE
LUXURY
MANUAL A/C
MANUAL A/C AUTOMATIC A/C
MEMORY SEAT/MIRROR/ ADJUSTABLE PEDALS MODULE DRIVER POWER SEAT SWITCH
NCA WIRE
ORG/ WIRE
OXYGEN SENSOR 1/2 DOWN STREAM
OXYGEN SENSOR-1/1 UPSTREAM
POWER POWER OUTLET OUTLET
POWERTRAIN CONTROL MODULE
RADIATOR FAN 1
RADIATOR FAN 2
RADIATOR FAN RELAY
REAR VIEW MIRROR)
RIGHT FOG LAMP
RIGHT FRONT PARK/TURN SIGNAL LAMP
SENTRY KEY REMOTE ENTRY MODULE (SKREEM)
TAN WIRE
TRACTION CONTROL SWITCH
TRANSMISSION CONTROL RELAY
VIO WIRE
W/ ABS
W/ MEMORY W/O MEMORY
W/O ABS
W/O DRIVER W/ DRIVER HEATED SEAT HEATED SEAT
WASHER FLUID LEVEL SWITCH
WHT WIRE
YEL WIRE
Go to component -> Ground distribution circuit (1 of 3) -> MEMORY SEAT/MIRROR/ ADJUSTABLE PEDALS MODULE DRIVER POWER SEAT SWITCH
