Dodge Caravan IV (2000-2007) front reading lamps/ switch Wiring diagrams
This page contains all the electrical diagrams for the component. front reading lamps/ switch, in which he is found in the car Dodge Caravan IV (2000-2007). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
front reading lamps/ switch wiring diagram (1 of 2)
BASE
BASE MIDLINE/ PREMIUM
BLK WIRE
BLK/BRN WIRE
BLK/ORG WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BODY CONTROL MODULE
BRN WIRE
CENTER HIGH MOUNTED STOP LAMP
DK BLU WIRE
DOOR
EXCEPT BASE
EXCEPT HANDS FREE
FROM GROUND
FRONT READING LAMPS/ SWITCH
GRN WIRE
GRY WIRE
LEFT VISOR/VANITY LAMP
LICENSE LAMP
LT BLU WIRE
LT GRN WIRE
MANUAL SLIDING
OCCUPANT CLASSIFICATION MODULE
ORG/ WIRE
PASSENGER HEATED SEAT BACK PASSENGER HEATED SEAT MODULE
PASSENGER HEATED SEAT CUSHION
PASSENGER POWER SEAT SWITCH
POWER SLIDING DOOR
PREMIUM
RADIO
REAR DOME LAMP
REAR WINDOW DEFOGGER GRID
REAR WIPER MOTOR
RIGHT CINCH/ RELEASE MOTOR BASE/ MIDLINE
RIGHT FRONT DOOR AJAR SWITCH PASSENGER DOOR LOCK SWITCH
RIGHT FRONT DOOR LOCK MOTOR/AJAR SWITCH (LUXURY) PASSENGER DOOR COURTESY LAMP
RIGHT FULL OPEN SWITCH
RIGHT LIFTGATE FLOOD LAMP
RIGHT SLIDING DOOR CONTROL MODULE
RIGHT SLIDING DOOR LATCH SENSING SWITCH
RIGHT SLIDING DOOR LOCK MOTOR
RIGHT SLIDING DOOR LOCK MOTOR/AJAR SWITCH
RIGHT SLIDING DOOR MOTOR
RIGHT VISOR/VANITY LAMP SUNROOF SWITCH
TAN WIRE
W/ POWER LIFTGATE W/ POWER RELEASE
W/ W/O PASSENGER HEATED SEAT PASSENGER HEATED SEAT
W/O PASSENGER POWER SEAT W/ PASSENGER POWER SEAT
WHT WIRE
YEL WIRE
Go to component -> Ground distribution circuit (3 of 3) -> FRONT READING LAMPS/ SWITCH
front reading lamps/ switch wiring diagram (2 of 2)
A/C HEATER CONTROL (CENTER OF DASH)
ASH/ RECEIVER LAMP FEED
AUTO TEMPERATURE CONTROL
AUTOMATIC A/C
BASE
BASE/ HIGHLINE PREMIUM
BLK WIRE
BLK/DK GRN WIRE
BLK/LT BLU WIRE
BLK/ORG WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
DK BLU WIRE
DOOR LOCK MOTOR/ AJAR SWITCH (IN LEFT FRONT DOOR)
EXCEPT BASE
EXCEPT BASE BASE
EXCEPT FRONT CONSOLE
FLOOR CONSOLE LAMP
FLOOR CONSOLE POWER OUTLET
FRONT CONSOLE
FRONT FLOOR CONSOLE
FRONT READING LAMPS/ SWITCH
GRY WIRE
LEFT FRONT
LEFT FRONT DOOR AJAR SWITCH
LEFT MID READING LAMP (PREMIUM/ LUXURY)
LEFT REAR READING LAMP (PREMIUM/ LUXURY)
LEFT VISOR/ VANITY LAMP (PREMIUM/ LUXURY)
LT BLU WIRE
LT BLU/PNK WIRE
MANUAL A/C
ORG/ WIRE
ORG/DK GRN WIRE
ORG/GRY WIRE
OVERHEAD CONSOLE (EXCEPT BASE)
PNK WIRE
REAR AUTO TEMPERATURE CONTROL SWITCH
REAR BLOWER REAR CONTROL SWITCH
REAR DOME LAMP (EXCEPT LUXURY)
REAR FLOOR CONSOLE
RIGHT FRONT DOOR AJAR SWITCH (AT "B" PILLAR)
RIGHT FRONT DOOR LOCK MOTOR/ AJAR SWITCH (IN RIGHT FRONT DOOR)
RIGHT MID READING LAMP (PREMIUM/ LUXURY)
RIGHT REAR READING LAMP (LUXURY)
RIGHT VISOR/ VANITY LAMP (PREMIUM/ LUXURY)
VIO WIRE
VIO/WHT WIRE
WHT WIRE
YEL WIRE
YEL/BRN WIRE
YEL/LT BLU WIRE
YEL/ORG WIRE
Go to component -> Interior lights circuit (2 of 2) -> FRONT READING LAMPS/ SWITCH
