Dodge Caravan IV (2000-2007) front control module sw out put Wiring diagram
This page shows the only wiring diagram for the component.front control module sw out put, which is found in the car Dodge Caravan IV (2000-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front control module sw out put (1 of 1)
BATTERY
BLK WIRE
CHARGING CIRCUIT
DK GRN WIRE
FRONT CONTROL MODULE SW OUT PUT
FUSE 9
FUSIBLE LINK (10 GA-
GENERATOR
GRY WIRE
HOLD-IN
HOT AT ALL TIMES
IGNITION SWITCH
INTEGRATED POWER MODULE (LEFT FRONT OF ENGINE COMPT)
INTEGRATED POWER MODULE FUSE 23 (LEFT FRONT OF ENGINE COMPARTMENT)
LOCK
LT BLU WIRE
LT BLU/RED WIRE
NCA WIRE
OFF
ORG/ WIRE
POWERTRAIN CONTROL MODULE (LEFT REAR OF TRANSAXLE) IGNITION SWITCH OUTPUT
PULL- IN
RED WIRE
RUN WIRE
STARTER MOTOR
STARTER MOTOR RELAY
STARTER RELAY CONTROL
YEL WIRE
