Dodge Caravan IV (2000-2007) front control module front control module fuse 12 Wiring diagram
This page shows the only wiring diagram for the component.front control module front control module fuse 12, which is found in the car Dodge Caravan IV (2000-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front control module front control module fuse 12 (1 of 1)
20 10 (LATE BUILD) (EARLY BUILD)
ACCESSORY RELAY
AMPLIFIER
AUTOMATIC A/C MANUAL A/C
BLK WIRE
BLOWER MOTOR RESISTOR FRONT BLOWER MODULE
BODY CONTROL MODULE
BRN WIRE
DK BLU WIRE
FLOOR CONSOLE LAMP (REAR POSITION)
FLOOR CONSOLE POWER OUTLET
FROM FUSE 23 (DIAGRAM 2 OF 3)
FROM FUSE 28 (DIAGRAM 1 OF 3)
FROM FUSE 9 (DIAGRAM 1 OF 3)
FRONT BLOWER MOTOR RELAY
FRONT CIGAR LIGHTER
FRONT CONTROL MODULE
FRONT CONTROL MODULE FRONT CONTROL MODULE FUSE 12
FUEL PUMP RELAY
FUSE 10
FUSE 23
FUSE 5
FUSE 6
GRY WIRE
IGNITION SWITCH
KEY OUT KEY IN
LOCK OFF
LT BLU WIRE
MANUAL A/C AUTOMATIC A/C
ORG/ WIRE
PARK ASSIST MODULE
PNK PNK WIRE
PNK WIRE
PNK/WHT WIRE
POWER MODULE
PTC 4 FUSE 13
RADIO (BEHIND LEFT SIDE OF DASH)
REAR A/C HEATER UNIT REAR BLOWER MOTOR POWER MODULE
REAR BLOWER MOTOR RELAY (3 ZONE HVAC)
REAR POSITION
REAR POWER OUTLET
REAR WINDOW DEFOGGER GRID LEFT POWER MIRROR
RED WIRE
RIGHT POWER MIRROR
RUN WIRE
SENTRY KEY REMOTE ENTRY MODULE (SKREEM)
STARTER MOTOR RELAY
TO FRONT BLOWER MOTOR RELAY (DIAGRAM 2 OF 3)
TO FUSE 14
VIO WIRE
W/ REAR FLOOR CONSOLE
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (2 of 3) -> FRONT CONTROL MODULE FRONT CONTROL MODULE FUSE 12
