Dodge Caravan IV (2000-2007) floor console floor console lamp power outlet Wiring diagram

3 ZONE AUTOMATIC A/C 3 ZONE MANUAL A/C AMPLIFIER BASE BLK WIRE BLK/BRN WIRE BLK/DK GRN WIRE BLK/LT GRN WIRE BLK/TAN WIRE BLK/WHT WIRE BRAKE FLUID LEVEL SWITCH (OR BRAKE LAMP SWITCH BRN WIRE DATA LINK CONNECTOR (DLC) DK BLU WIRE DK GRN WIRE DRIVER DOOR LOCK SWITCH EXCEPT BASE FLOOR CONSOLE FLOOR CONSOLE LAMP POWER OUTLET FLOOR CONSOLE POWER OUTLET FLOOR CONSOLE LAMP FRONT POSITION FUEL PUMP MODULE GRY WIRE INTEGRATED POWER MODULE (LEFT FRONT OF ENGINE COMPT) FRONT CONTROL MODULE LEFT CINCH/ RELEASE MOTOR LEFT FRONT DOOR AJAR SWITCH LEFT FRONT DOOR LOCK MOTOR/AJAR SWITCH LEFT FULL OPEN SWITCH LEFT HEADLAMP LEFT REAR LAMP ASSEMBLY LEFT SLIDING DOOR CONTROL MODULE LEFT SLIDING DOOR LATCH SENSING SWITCH LEFT SLIDING DOOR LOCK MOTOR LEFT SLIDING DOOR LOCK MOTOR/AJAR SWITCH LEFT SLIDING DOOR MOTOR LICENSE LAMP LIFTGATE CINCH/ RELEASE MOTOR LIFTGATE RIGHT PINCH SENSOR POWER LIFTGATE MOTOR LT BLU WIRE LT GRN WIRE MANUAL SLIDING DOOR NCA WIRE ORG/ WIRE PARK ASSIST MODULE POWER LIFTGATE MODULE POWER SLIDING DOOR REAR AUTOMATIC TEMPERATURE CONTROL SWITCH REAR BLOWER REAR CONTROL SWITCH REAR POSITION REAR POWER OUTLET RIGHT HEADLAMP RIGHT REAR LAMP ASSEMBLY SUNROOF MODULE TAN WIRE TO GROUND VIO WIRE W/ TRAILER TOW W/O TRAILER TOW TRAILER TOW CONNECTOR WHT WIRE WIPER MODULE
