Dodge Caravan IV (2000-2007) eng/diseng sw Wiring diagram

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 HALL EFFECT 1 2 3 4 5 6 7 8 LATCH CLUTCH OPEN DRV CLOSE DRV BLK/LT GRN WIRE BLK/ORG WIRE BLK/WHT WIRE CLUTCH EARLY BUILD ENG/DISENG SW ENGAGE/ DISENGAGE SWITCH FRONT CONTROL MODULE PCI BUS FUSE 32 FUSED B (+) GROUND HALL EFFECT HOT AT ALL TIMES INTEGRATED POWER MODULE (LEFT FRONT OF ENGINE COMPT) LIFTGATE FULL OPEN SWITCH LIFTGATE LEFT PINCH SENSOR (AT LEFT SIDE OF LIFTGATE) LIFTGATE RIGHT PINCH SENSOR (AT RIGHT SIDE OF LIFTGATE) ORG/ WIRE ORG/DK BLU WIRE ORG/GRY WIRE ORG/LT BLU WIRE ORG/LT GRN WIRE ORG/YEL WIRE PINCH SENS SIG POWER LIFTGATE MODULE (MOUNTED ON LEFT "D" PILLAR) POWER LIFTGATE MOTOR (IN LEFT "D" PILLAR) POWER TOPS SYSTEM RED WIRE TAN/BRN WIRE TAN/DK BLU WIRE TAN/GRY WIRE TAN/LT GRN WIRE TAN/ORG WIRE TAN/VIO WIRE TAN/WHT WIRE TAN/YEL WIRE TEMP SENS SIG HALL EFFECT SIG CHIME DRV WAKE UP SIG GROUND VIO WIRE VIO/DK GRN WIRE VIO/LT BLU WIRE VIO/ORG WIRE W/ SUNROOF WHT WIRE WHT/VIO WIRE YEL WIRE YEL/RED WIRE
