Dodge Caravan IV (2000-2007) 4 5 3 ign sw run driver seat sw passen seat sw Wiring diagram

1 2 3 4 GND SEAT SW IGN SW OUT FUSED B(+) 1 2 HTR (B+) HTR GND 4 5 3 IGN SW RUN DRIVER SEAT SW PASSEN SEAT SW 6 7 8 HTR GROUND HTR B(+) IGN SW OUT BLK/ORG WIRE BODY CONTROL MODULE (BEHIND LEFT SIDE OF DASH) DK BLU WIRE DK GRN WIRE DRIVER HEATED SEAT CUSHION (IN DRIVER'S SEAT) DRIVER HEATED SEAT MODULE (BELOW DRIVER'S SEAT) FUSED B (+) GND B+ GRY WIRE GRY/PNK WIRE HOT AT ALL TIMES POWER SEAT CIRCUIT BREAKER (UNDER DRIVER'S SEAT) HTR B(+) HTR GND HTR B(+) HTR GROUND HTR GND B(+) GND GND IGN SW RUN INSTRUMENT PANEL SWITCH BANK LT GRN/DK GRN WIRE LT GRN/WHT WIRE MEMORY SYSTEMS, POWER SEAT CIRCUIT ORG/RED WIRE PASSENGER HEATED SEAT CUSHION (IN PASSENGER'S SEAT) PASSENGER HEATED SEAT MODULE (BELOW PASSENGER'S SEAT) RED WIRE SEAT SW GROUND TEMP SENS IN TEMP SENS IN 1 2 3 4 WHT/PNK WIRE
