Dodge Caravan IV (2000-2007) 34 5 chime driver wake up sense Wiring diagram

34 5 CHIME DRIVER WAKE UP SENSE 5 8 RIGHT SLIDING DOOR AJAR LEFT SLIDING DOOR AJAR BASE BLK/BRN WIRE BLK/DK GRN WIRE BLK/ORG WIRE BLK/VIO WIRE BLK/WHT WIRE BODY CONTROL MODULE (BEHIND LEFT SIDE OF DASH) BRN/RED WIRE CONTROL SWITCH DK BLU WIRE DK BLU/WHT WIRE DK GRN/WHT WIRE DOOR AJAR SWITCH SENSE EXCEPT BASE FUEL LEVEL SENSOR FUEL PUMP MODULE (SIDE OF FUEL TANK) FUSED B (+) HI BEAM/WASHER SW MUX HIGH BEAM/ WASHER SW MUX MULTI- FUNCTION SWITCH (LEFT SIDE OF DASH) LEFT FRONT DOOR AJAR SWITCH LEFT FRONT DOOR LOCK MOTOR/AJAR SWITCH (IN LEFT FRONT DOOR) LEFT TURN IND DRIVER LIFTGATE AJAR SWITCH (IN LIFTGATE) LIFTGATE CINCH/ RELEASE MOTOR (IN LIFTGATE) LT GRN WIRE MANUAL LIFTGATE MANUAL SLIDING DOOR ORG/WHT WIRE PANEL LAMPS DRIVER POWER LIFTGATE POWER SLIDING DOOR RIGHT FRONT DOOR AJAR SWITCH (AT "B" PILLAR) RIGHT FRONT DOOR LOCK MOTOR/AJAR SWITCH (IN RIGHT FRONT DOOR) RIGHT TURN IND DRIVER TAN/ORG WIRE TRACT CTRL SWITCH SENSE TRACTION CTRL SW SENSE TRUNK, TAILGATE, FUEL DOORS SYSTEM VIO WIRE VIO/BRN WIRE VIO/GRY WIRE VIO/ORG WIRE VIO/WHT WIRE VIO/YEL WIRE WHT WIRE WHT/LT GRN WIRE WHT/TAN WIRE WHT/VIO WIRE
