Dodge Caravan IV (2000-2007) 3 2 1 sens pwr sens signal sens ground Wiring diagram

1 2 3 SENS PWR SENS GROUND SENS SIGNAL 1 2 GROUND SIGNAL 1 2 SW SENS GROUND 2 1 SIGNAL GROUND 2 1 SW SENSE GROUND 3 2 1 SENS PWR SENS SIGNAL SENS GROUND AIR BAG WARNING INDICATOR BATTERY B(+) PCI BUS BELT TENSION SENSOR BLK/LT BLU WIRE BLK/LT GRN WIRE BRN WIRE BRN/LT GRN WIRE CLOCKSPRING COMPUTER DATA LINES SYSTEM DK BLU WIRE DRIVER AIR BAG SQUIB 1 DRIVER AIR BAG SQUIB 2 DRIVER SEAT BELT SWITCH (AT SWITCH ON GROUND HOT AT ALL TIMES INSTRUMENT CLUSTER LEFT CURTAIN AIR BAG SQUIB (REAR OF LEFT ROOF RAIL) LEFT SIDE IMPACT SENSOR 1 (AT LEFT "B" PILLAR) LEFT SIDE IMPACT SENSOR 2 (IN LEFT SLIDING DOOR) LINE 1- LINE 2- LT BLU WIRE LT BLU/DK BLU WIRE LT BLU/GRY WIRE LT BLU/ORG WIRE LT BLU/TAN WIRE LT BLU/WHT WIRE LT BLU/YEL WIRE LT GRN WIRE LT GRN/BRN WIRE LT GRN/DK GRN WIRE LT GRN/GRY WIRE LT GRN/LT BLU WIRE LT GRN/ORG WIRE LT GRN/TAN WIRE LT GRN/VIO WIRE LT GRN/WHT WIRE NCA WIRE OCCUPANT CLASSIFICATION MODULE (IN PASSENGER SEAT) ORG/ WIRE PASSENGER SEAT BELT SWITCH (EARLY BUILD OCCUPANT SENSING) (AT SEAT BELT BUCKLE) PASSENGER SEAT BELT TENSIONER (AT PASSENGER'S SEAT BELT) PASSENGER SEAT WEIGHT SENSOR (IN PASSENGER SEAT) PNK/ORG WIRE RIGHT SIDE IMPACT SENSOR 1 (AT RIGHT "B" PILLAR) RIGHT SIDE IMPACT SENSOR 2 (IN RIGHT SLIDING DOOR) SEAT HARNESS) SENS GROUND SENS GROUND SENS PWR SENS SIGNAL GROUND SENS SIGNAL SENS PWR PCI BUS ORC RUN-START TAN WIRE TAN/LT GRN WIRE VIO WIRE WHT WIRE WHT/LT GRN WIRE WHT/ORG WIRE WHT/VIO WIRE
