Dodge Caravan III (1995-2000) head park wiring diagram
This page shows the only wiring diagram for the component.head park, which is found in the car Dodge Caravan III (1995-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
head park wiring diagram (1 of 1)
AUTO OFF
BLK WIRE
BLK/LT BLU WIRE
BLK/LT GRN WIRE
BLK/TAN WIRE
BLK/WHT WIRE
BODY CONTROL MODULE
BRN/TAN WIRE
CCD BUS (-) CCD BUS (+)
CLUSTER ILLUM LAMPS
COMPUTER DATA LINES SYSTEM
DATA LINK CONNECTOR (LEFT SIDE OF DASH)
DK BLU WIRE
FUSE 2
FUSE 28
FUSE 6
FUSED IGN SW (RUN/ START) FUSED IGN SW (RUN/ START/ FUSED B(+)
FUSED IGN SW (RUN/ACC)
GROUND
GRY WIRE
HEAD PARK
HEADLAMP SWITCH CTSY LP SW
HOT AT ALL TIMES
HOT IN RUN
HOT IN RUN OR
IGNITION SWITCH
INSTRUMENT CLUSTER
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
KEY-IN SWITCH
LEFT FRONT DOOR AJAR SWITCH
LOCK OFF
LT BLU WIRE
LT GRN/RED WIRE
LT GRN/WHT WIRE
MEMORY SEAT, MIRROR MODULE
OF STEERING COLUMN)
OFF
OR OFF
PNK WIRE
POWER DISTRIBUTION CENTER (LEFT SIDE OF ENGINE COMPT)
RF DOOR AJAR SWITCH LR DOOR AJAR SWITCH FUEL PUMP MODULE HOOD AJAR SWITCH
RR DOOR AJAR SWITCH LIFTGATE AJAR SWITCH LOW WASHER FLUID SWITCH
RUN WIRE
SEAT BELT SWITCH
SEATBELT INDICATOR
SEATBELT INDICATOR CTRL
TAN WIRE
TAN/BLK WIRE
TAN/ORG WIRE
TAN/RED WIRE
TAN/YEL WIRE
VIO/BRN WIRE
W/ OVERHEAD W/O OVERHEAD
WHT/BLK WIRE
Go to component -> Warning system circuits -> HEAD PARK
