Chime circuit for Dodge Caliber I facelift (2009-2013)

2 3 B(+) LIN CCN 7 6 1 CAN BUS (-) CAN BUS (+) IGN SW SNS B(+) BEHIND LEFT QUARTERPANEL) BLK WIRE BLK/LT BLU WIRE BLK/WHT WIRE BLK/YEL WIRE BRK LVL SIG BRN WIRE CAN-BUS CLUSTER COMPUTER DATA LINES SYSTEM DK BLU WIRE DK GRN WIRE DK GRN/LT BLU WIRE DK GRN/RED WIRE DRIVER DOOR LATCH SNS DRIVER SEAT BELT SW SNS DRIVER SEAT BELT SWITCH (INTEGRAL TO DRIVER SEAT BELT BUCKLE ASSEMBLY) FUSE 14 FUSE 17 GROUND GRY WIRE HOT AT ALL TIMES IGNITION SWITCH IGN SW SNS IOD FD LEFT MULTI FUNCTION SWITCH LEFT REAR DOOR LATCH SNS LF DR AJAR SW SNS LIFTGATE AJAR SW SNS LIFTGATE DOOR LATCH LIN CNN LR DR AJAR SW SNS LT BLU WIRE LT GRN WIRE LT GRN/GRY WIRE ORG/ WIRE PARK BRAKE SW SNS PARKING BRAKE SWITCH (BASE OF PARKING BRAKE LEVER ASSEMBLY) PASSENGER PNK WIRE RED WIRE RED/DK BLU WIRE RED/LT GRN WIRE RF DR AJAR SW SNS RIGHT REAR DOOR LATCH RR DOOR AJAR SW SNS SENS SNS DOOR LATCH GND VIO WIRE VIO/BRN WIRE VIO/DK BLU WIRE VIO/GRY WIRE VIO/ORG WIRE VIO/WHT WIRE VIO/YEL WIRE WHT WIRE WHT/DK GRN WIRE WHT/ORG WIRE WHT/PNK WIRE WIRELESS IGNITION NODE YEL WIRE
