Dodge Caliber I facelift (2009-2013) Charging circuit

11 3 CAN B BUS (-) CAN B BUS (+) 57 33 CAN C BUS (+) CAN C BUS (-) ALTR FIELD CTRL ALTR SENSE B(+) BATTERY BRN/GRY WIRE CAN B BUS (+) CIRCUIT BOARD CLUSTER COMPUTER DATA LINES SYSTEM DK GRN WIRE GENERATOR POWERTRAIN CONTROL MODULE (LEFT REAR OF ENGINE COMPT) RED WIRE RED/GRY WIRE STARTER TOTALLY INTEGRATED POWER MODULE (LEFT SIDE OF ENGINE COMPT) WHT/BLK WIRE WHT/LT BLU WIRE WHT/ORG WIRE WHT/PNK WIRE
