Anti-lock brakes circuit for Dodge Caliber I (2006-2009)

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 FUSED B(+) (PUMP) ANTI-LOCK BRAKES MODULE (REAR OF ENGINE COMPT) B(+) CAN B BUS (+) CAN B BUS (-) BANK SWITCH BLK/LT GRN WIRE BLK/WHT WIRE CAN C BUS (+) CAN C BUS (-) COMPUTER DATA LINES SYSTEM DK GRN/LT BLU WIRE DK GRN/LT GRN WIRE DK GRN/ORG (OR YEL/DK BLU) WIRE DK GRN/ORG WIRE DK GRN/TAN WIRE DK GRN/WHT WIRE DYNAMIC SENS GND DYNAMIC SENS HIGH DYNAMIC SENS LOW DYNAMIC SENS SPLY DYNAMICS SENSOR (W/ ESP) (UNDER FRONT OF CENTER CONSOLE) ELECTRONICS STOP LAMP SW OUT FUSE 3 FUSE 33 FUSE 34 FUSE 35 FUSED B(+) (VALVE) RF WHL SPD SENS SIG GROUND GROUND FUSED B(+) LIN BUS HOT AT ALL TIMES IGN SW OUT (RUN-START) LEFT FRONT ABS WHEEL SPEED SENSOR (LEFT SIDE OF ENGINE COMPT) LEFT REAR ABS WHEEL SPEED SENSOR (AT LEFT REAR WHEEL ASSEMBLY) LF WHL SPD SENS SIG GROUND LR WHL SPD SENS SIG LT GRN WIRE LT GRN/BLK WIRE LT GRN/DK BLU WIRE PNK/GRY WIRE RED/BLK WIRE RED/DK BLU WIRE RED/LT BLU WIRE RIGHT FRONT ABS WHEEL SPEED SENSOR (RIGHT SIDE OF ENGINE COMPT) RIGHT REAR ABS WHEEL SPEED SENSOR (AT RIGHT REAR WHEEL ASSEMBLY) RR WHL SPD SENS SIG STOP LAMP SWITCH (TOP OF BRAKE PEDAL ASSEMBLY) TCS OFF TOTALLY INTEGRATED POWER MODULE (LEFT SIDE OF ENGINE COMPT) VIO/DK BLU WIRE VIO/LT BLU WIRE WHT WIRE WHT/BLK WIRE WHT/DK BLU WIRE WHT/DK GRN WIRE WHT/LT BLU WIRE WHT/ORG WIRE WHT/PNK WIRE WHT/YEL WIRE YEL WIRE YEL/DK BLU WIRE
