Dodge Cab & Chassis R3500 (1996-2006) Warning system circuits

BASE/MIDLINE BLK WIRE BLK/LT GRN WIRE BLU WIRE CENTRAL TIMER MODULE (LEFT SIDE OF DASH) DK BLU WIRE DK BLU/RED WIRE DK BLU/WHT WIRE DRIVER DOOR AJAR SWITCH FUSE 11 FUSE 13 FUSE 6 FUSED B (+) FUSED IGN GROUND HEADLAMP SWITCH HOT AT ALL TIMES HOT IN RUN OR ACC HOT IN RUN OR START IGNITION SWITCH INSTRUMENT CLUSTER J/C 6 (BEHIND LEFT SIDE OF DASH) J/C 8 (CENTER OF DASH) JUNCTION BLOCK (LEFT END OF DASH) KEY-IN SWITCH (LEFT KICK PANEL) KEY-IN/LIGHTS ON WARNING KEY-IN/ LF DR AJAR SWITCH SENSE LT BLU WIRE LT GRN WIRE OFF RED WIRE SEAT BELT IND SEAT BELT SWITCH SEAT- BELT SW SENSE TONE REQUEST STANDARD CAB TAN WIRE TONE REQUEST WHT WIRE
