Dodge Avenger II facelift (2011-2014) driver front varistor wiring diagram
This page shows the only wiring diagram for the component.driver front varistor, which is found in the car Dodge Avenger II facelift (2011-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
driver front varistor wiring diagram (1 of 1)
1 2 3 PWR RCLNR MTR AFT
BATT FEED
BLK WIRE
DRIVER FRONT VARISTOR
DRIVER HORIZONTAL VARISTOR
DRIVER REAR VARISTOR
DRIVER SEAT FRONT VERTICAL ADJUSTER MOTOR
DRIVER SEAT HORIZONTAL ADJUSTER MOTOR
DRIVER SEAT REAR VERTICAL ADJUSTER MOTOR
DRIVER SEAT RECLINER ADJUSTER MOTOR
DRIVER SEAT SWITCH
LT GRN/DK GRN WIRE
LT GRN/GRY WIRE
LT GRN/LT BLU WIRE
LT GRN/ORG WIRE
LT GRN/TAN WIRE
LT GRN/VIO WIRE
LT GRN/WHT WIRE
LT GRN/YEL WIRE
NCA WIRE
PWR RCLNR MTR AFT
PWR RCLNR MTR FWD
PWR STS FT DWN
PWR STS FT UP
PWR STS HORZ AFT
PWR STS HORZ FWD
PWR STS RR VERT DN
PWR STS RR VERT DWN
PWR STS RR VERT UP
RED WIRE
Go to component -> Driver power seat circuit -> DRIVER FRONT VARISTOR
