Dodge Avenger II (2007-2010) decklid release driver wiring diagram
This page shows the only wiring diagram for the component.decklid release driver, which is found in the car Dodge Avenger II (2007-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
decklid release driver wiring diagram (1 of 1)
BLK WIRE
CLUSTER DECKLID RELEASE SWITCH SENS
DECKLID AJAR SWITCH SENS
DECKLID AJAR SWITCH SENS CARGO LAMP
DECKLID DOOR LATCH (AT CENTER REAR OF DECK LID)
DECKLID RELEASE DRIVER
DECKLID RELEASE SWITCH
DOOR LOCK POWER FUSE B(+)
FUSE 10
HOT AT ALL TIMES
LT GRN WIRE
RED/WHT WIRE
TAN/YEL WIRE
TOTALLY INTEGRATED POWER MODULE (LEFT SIDE OF ENGINE COMPT)
VIO/ORG WIRE
WHT WIRE
Go to component -> Deck lid release circuit -> DECKLID RELEASE DRIVER
