Anti-lock brake circuits for Dodge Avenger I (1994-2000)

8 C-06 ABS INDICATOR ABS-ECU (AT LEFT FRONT CORNER OF ENGINE COMPARTMENT) B-42 B-54 BLK WIRE BLK/BLU WIRE BLK/RED WIRE BLK/WHT WIRE BLU/BLK WIRE COMBINATION METER DATA LINK CONNECTOR (UNDER LEFT SIDE OF DASH, NEAR CENTER CONSOLE) DEDICATED FUSE 1 ENGINE COMPARTMENT RELAY BOX FUSE 13 FUSE 8 FUSIBLE LINK 7 GRN WIRE GRN/RED WIRE GRY/BLU WIRE GRY/RED WIRE HOT AT ALL TIMES HOT IN ON HOT IN ON OR START HYDRAULIC UNIT J/C 1 (LEFT SIDE OF DASH) J/C 2 (LEFT SIDE OF DASH) JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH) LEFT FRONT SPEED SENSOR (ON LEFT FRONT WHEEL ASSEMBLY) LEFT REAR SPEED SENSOR (ON LEFT REAR WHEEL ASSEMBLY) NCA WIRE PNK WIRE RED/BLK WIRE RESISTOR RIGHT FRONT SPEED SENSOR (ON RIGHT FRONT WHEEL ASSEMBLY) RIGHT REAR SPEED SENSOR (ON RIGHT REAR WHEEL ASSEMBLY) SOLENOID VALVE STOP LIGHT SWITCH (ON BRAKE PEDAL BRACKET) WHT/BLU WIRE WHT/RED WIRE YEL WIRE YEL/BLU WIRE YEL/RED WIRE
