Dodge Avenger I (1994-2000) right headlight Wiring diagrams
This page contains all the electrical diagrams for the component. right headlight, in which he is found in the car Dodge Avenger I (1994-2000). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
right headlight wiring diagram (1 of 2)
B-09
B-09 LIGHTING SWITCH
B-10
B-54
B-63
B-63 JUNCTION BLOCK (LEFT SIDE OF DASH)
BLK WIRE
BLU WIRE
BLU/RED WIRE
C-05
DIMMER/PASSING SWITCH
DRL-ECU (AT LEFT HEADLAMP ASSEMBLY)
FOG LIGHT RELAY (IN ENG COMPT RELAY BOX)
FOG LIGHT SWITCH
FUSE 5
FUSE 6
FUSIBLE LINK 4
GRN WIRE
HEADLIGHT RELAY (IN ENG COMPT RELAY BOX)
HI BEAM RELAY (AT LEFT HEADLAMP ASSEMBLY)
HIGH BEAM INDICATOR
HOT AT ALL TIMES
HOT IN RUN JUNCTION BLOCK (LEFT SIDE OF DASH) FUSE 13
HOT W/ HEAD/ TAIL LIGHTS ON
INSTRUMENT CLUSTER
INTERIOR LIGHTS SYSTEM (RHEOSTAT)
J/C 1 (BEHIND LEFT SIDE OF DASH)
J/C 2 (BEHIND LEFT SIDE OF DASH)
LEFT FOG LIGHT
LEFT HEADLIGHT
LIGHTING SWITCH
LO HI
NCA WIRE
OFF HEAD
OFF ON
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RIGHT FOG LIGHT
RIGHT HEADLIGHT
TAIL
WHT WIRE
YEL WIRE
Go to component -> Headlamps/fog lamps circuit, with drl -> RIGHT HEADLIGHT
right headlight wiring diagram (2 of 2)
B-09
B-09 LIGHTING SWITCH
B-10
B-54
B-63 JUNCTION BLOCK (LEFT SIDE OF DASH)
BLK WIRE
C-05
DIMMER/PASSING SWITCH
ENGINE COMPARTMENT RELAY BOX (LEFT SIDE OF ENG COMPT, INFRONT OF WHEEL HOUSING)
ENGINE COMPARTMENT RELAY BOX FUSE 4
FOG LIGHT RELAY (IN ENG COMPT RELAY BOX)
FOG LIGHT SWITCH
FUSE 5
FUSE 6
FUSIBLE LINK 4
GRN/BLK WIRE
GRN/BLU WIRE
GRN/WHT WIRE
HEADLIGHT RELAY (IN ENG COMPT RELAY BOX)
HIGH BEAM INDICATOR
HOT AT ALL TIMES
HOT W/ HEAD/ TAIL LIGHTS ON
INSTRUMENT CLUSTER
INTERIOR LIGHTS SYSTEM (RHEOSTAT)
J/C 1 (BEHIND LEFT SIDE OF DASH)
J/C 2 (BEHIND LEFT SIDE OF DASH)
LEFT FOG LIGHT
LEFT HEADLIGHT
LIGHTING SWITCH
LO HI
NCA WIRE
OFF
OFF HEAD
OFF ON
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RIGHT FOG LIGHT
RIGHT HEADLIGHT
TAIL
YEL WIRE
YEL/RED WIRE
Go to component -> Headlamps/fog lamps circuit, without drl -> RIGHT HEADLIGHT
