Dodge Avenger I (1994-2000) lock connector lock switch wiring diagram
This page shows the only wiring diagram for the component.lock connector lock switch, which is found in the car Dodge Avenger I (1994-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
lock connector lock switch wiring diagram (1 of 1)
** AVENGER/ SEBRING COUPE
AIR BAG MODULE (DRIVER'S SIDE) (CENTER OF STEERING WHEEL)
AIR BAG MODULE (PASSENGER'S SIDE) (ABOVE GLOVE COMPARTMENT)
B-50 B-42 **
B-51 B-43 **
B-66 B-54 **
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
C-04
C-06 INSTRUMENT CLUSTER SRS IND.
CLOCK- SPRING
DATA LINK CONNECTOR (UNDER LEFT SIDE OF DASH, NEAR CENTER CONSOLE)
FUSE 3
FUSE 8
GRN/YEL WIRE
HOT IN START OR RUN
J/C 1 (BEHIND LEFT SIDE OF DASH)
J/C 2 (BEHIND LEFT SIDE OF DASH)
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
LOCK CONNECTOR LOCK SWITCH
NCA WIRE
TALON
UNLOCK
YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Supplemental restraint circuit -> LOCK CONNECTOR LOCK SWITCH
