Supplemental restraints circuit for Daewoo Nubira II (1999-2003)
Supplemental restraints circuit
AIR BAG CONTROL UNIT
AIR BAG IND
BLK WIRE
BLK/WHT WIRE
BRN WIRE
CHIME
CLOCK- SPRING
CLUSTER
DATA LINK CONNECTOR
DK GRN WIRE
DK GRN/WHT WIRE
DRIVER AIR BAG MODULE
DRIVER SIDE PRETENSIONER PASSENGER SIDE PRETENSIONER
FUSE 6 FUSE 5
FUSE BOX
GRY WIRE
HOT IN RUN OR START
LT BLU WIRE
NCA WIRE
NOTE: THERE IS A SHORTING BAR BETWEEN PINS
PASSENGER AIR BAG MODULE
PNK PNK WIRE
PNK WIRE
SEAT BELT SWITCH
WHT WIRE
WHT/BLK WIRE
YEL WIRE
