Cooling fan circuit, with a/c for Daewoo Nubira II (1999-2003)
Cooling fan circuit, with a/c
A/C PRESSURE SENSOR (AT RIGHT FRONT CORNER OF ENGINE COMPT)
AIR CONDITIONING SYSTEM
AUX COOLING FAN (BEHIND RIGHT SIDE OF RADIATOR)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
COOLING FAN CONTROL RELAY
COOLING FAN HIGH RELAY
COOLING FAN LOW RELAY
ENGINE COMPARTMENT RELAY & FUSE BOX (AT LEFT SIDE OF ENGINE COMPT)
ENGINE CONTROL MODULE (BEHIND RIGHT KICK PANEL)
ENGINE COOLANT TEMPERATURE SENSOR (ON REAR OF CYLINDER HEAD)
FUSE 3
FUSE 8
GRN WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
IGNITION SWITCH
LOCK
LT BLU WIRE
LT BLU/BLK WIRE
LT BLU/WHT WIRE
MAIN COOLING FAN (BEHIND LEFT SIDE OF RADIATOR)
ORG/ WIRE
ORG/BLK WIRE
PASSENGER COMPARTMENT FUSE BOX (BEHIND LEFT SIDE OF DASH) FUSE 15
RED/BLK WIRE
RUN WIRE
SIG RELAY SW RELAY SW RELAY SW SIG SENS LO SENS HI SENS LO ACP SIG
SPLICE PACK 203 (BEHIND LEFT SIDE OF DASH)
SPLICE PACK 207 (BEHIND CENTER OF DASH)
SPLICE PACK 210 (RIGHT SIDE OF DASH)
VIO/WHT WIRE
WHT WIRE
YEL WIRE
