Daewoo Nubira II (1999-2003) Manual a/c circuit

A/C COMPRESSOR A/C COMPRESSOR RELAY A/C CONTROL SWITCH A/C PRESSURE SENSOR (AT RIGHT FRONT CORNER OF ENGINE COMPT) A/C SWITCH BLK WIRE BLOWER MOTOR BLOWER MOTOR RESISTOR BLOWER MOTOR SWITCH BLU WIRE BRN WIRE BRN/WHT WIRE COOLING FAN HIGH RELAY (DIAGRAM 2 OF 2) DIODE ENGINE COMPARTMENT RELAY & FUSE BOX (AT LEFT SIDE OF ENGINE COMPT) FUSE 33 ENGINE CONTROL MODULE (BEHIND RIGHT KICK PANEL) ENGINE COOLANT TEMPERATURE SENSOR (ON REAR OF CYLINDER HEAD) FUSE 2 GRN WIRE GRN/WHT WIRE HOT AT ALL TIMES IGNITION SWITCH INDICATOR LOCK LT BLU WIRE LT BLU/BLK WIRE OFF ORG/ WIRE ORG/BLK WIRE PASSENGER COMPARTMENT FUSE BOX (BEHIND LEFT SIDE OF DASH) FUSE 15 RECIRCULATION SOLENOID RECIRCULATION SWITCH RED WIRE RED/BLK WIRE RELAY RUN WIRE SIG RELAY SW RELAY SW RELAY SW SIG SENS LO SENS HI SENS LO ACP SIG SPLICE PACK 202 (LEFT SIDE OF DASH) SPLICE PACK 203 (BEHIND LEFT SIDE OF DASH) SPLICE PACK 207 (BEHIND CENTER OF DASH) SPLICE PACK 208 (CENTER OF DASH) SPLICE PACK 210 (RIGHT SIDE OF DASH) SWITCH ILLUMINATION (2 BULBS) VIO WIRE VIO/WHT WIRE WHT WIRE YEL WIRE

A/C COMPRESSOR RELAY (DIAGRAM 1 OF 2) AUX COOLING FAN (BEHIND RIGHT SIDE OF RADIATOR) BLK WIRE BLK/WHT WIRE BLU WIRE BRN WIRE COOLING FAN CONTROL RELAY COOLING FAN HIGH RELAY COOLING FAN LOW RELAY ENGINE COMPARTMENT RELAY & FUSE BOX (AT LEFT SIDE OF ENGINE COMPT) FUSE 3 FUSE 8 GRN WIRE HOT AT ALL TIMES LT BLU WIRE LT BLU/WHT WIRE MAIN COOLING FAN (BEHIND LEFT SIDE OF RADIATOR) WHT WIRE
