Daewoo Nubira II (1999-2003) trunk or luggage lamp Wiring diagram
This page shows the only wiring diagram for the component.trunk or luggage lamp, which is found in the car Daewoo Nubira II (1999-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram trunk or luggage lamp (1 of 1)
5 4 4 2 (W/ SUNROOF) (W/O SUNROOF)
ANTI-THEFT SYSTEM
BLK WIRE
DOOR OPEN WARNING LAMP
ENGINE COMPARTMENT FUSE, RELAY BOX (LEFT SIDE OF ENGINE COMPT)
FUSE 29
HOT AT ALL TIMES
INSTRUMENT CLUSTER
LEFT FRONT DOOR CONTACT SWITCH RIGHT REAR DOOR CONTACT SWITCH
LEFT REAR DOOR CONTACT SWITCH
MAP LAMP
ON DOOR OFF
ORG/ WIRE
PNK PNK WIRE
PNK WIRE
PNK/BLK WIRE
RIGHT FRONT DOOR CONTACT SWITCH
ROOM LAMP
TAILGATE OPEN SWITCH
TRUNK LID OPEN SWITCH
TRUNK OR LUGGAGE LAMP
WHT WIRE
Go to component -> Courtesy lamps circuit, except wagon -> TRUNK OR LUGGAGE LAMP
