Daewoo Nubira II (1999-2003) sk btsi and key interlock unit Wiring diagram
This page shows the only wiring diagram for the component.sk btsi and key interlock unit, which is found in the car Daewoo Nubira II (1999-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sk btsi and key interlock unit (1 of 1)
BLK WIRE
BRAKE SWITCH
BRN WIRE
BTSI SOLENOID
ENGINE COMPARTMENT FUSE AND RELAY BOX (LEFT SIDE OF ENGINE COMPT)
FUSE 24
FUSE 5
FUSE 9
GRN WIRE
HOT AT ALL TIMES
HOT IN ACCY AND ON
HOT IN ON OR START
KEY INTERLOCK
KEY INTERLOCK SOLENOID
LT GRN WIRE
ORG/ WIRE
PASSENGER COMPARTMENT FUSE BOX (BEHIND LEFT SIDE OF DASH)
PNK WIRE
PRND SWITCH
SHIFT INTERLOCK
SK BTSI AND KEY INTERLOCK UNIT
SPLICE PACK 202
SPLICE PACK 205
SPLICE PACK 208
YEL WIRE
