Daewoo Nubira II (1999-2003) right rear sub- switch Wiring diagram
This page shows the only wiring diagram for the component.right rear sub- switch, which is found in the car Daewoo Nubira II (1999-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right rear sub- switch (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
DOWN
ENGINE COMPARTMENT FUSE, RELAY BOX (AT LEFT SIDE OF ENGINE COMPARTMENT)
FUSE 15
FUSE 7
GRN WIRE
HOT AT ALL TIMES
HOT IN ON
IGNITION RELAY 2
LEFT FRONT POWER WINDOW MOTOR
LEFT REAR POWER WINDOW MOTOR
LEFT REAR SUB- SWITCH
LOCK UN- LOCK
NCA WIRE
ORG/ WIRE
PASSENGER COMPARTMENT FUSE BOX (BEHIND LEFT SIDE OF DASH)
POWER WINDOW SWITCH
RIGHT FRONT POWER WINDOW MOTOR
RIGHT FRONT SUB- SWITCH
RIGHT REAR POWER WINDOW MOTOR
RIGHT REAR SUB- SWITCH
SENSOR
VIO WIRE
Go to component -> Power windows circuit -> RIGHT REAR SUB- SWITCH
