Daewoo Nubira II (1999-2003) relay sw relay sw sig sens lo Wiring diagram
This page shows the only wiring diagram for the component.relay sw relay sw sig sens lo, which is found in the car Daewoo Nubira II (1999-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram relay sw relay sw sig sens lo (1 of 1)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
COOLING FAN HIGH RELAY
COOLING FAN LOW RELAY
COOLING FAN LOW SPEED RESISTOR
ENGINE COMPARTMENT RELAY & FUSE BOX (AT LEFT SIDE OF ENGINE COMPT)
ENGINE CONTROL MODULE (BEHIND RIGHT KICK PANEL)
ENGINE COOLANT TEMPERATURE SENSOR (ON REAR OF CYLINDER HEAD)
FUSE 3
FUSE 8
GRN WIRE
HOT AT ALL TIMES
IGNITION SWITCH
LOCK
MAIN COOLING FAN (BEHIND LEFT SIDE OF RADIATOR)
ORG/ WIRE
PASSENGER COMPARTMENT FUSE BOX (BEHIND LEFT SIDE OF DASH) FUSE 15
RELAY SW RELAY SW SIG SENS LO
RUN WIRE
SPLICE PACK 203 (BEHIND LEFT SIDE OF DASH)
SPLICE PACK 207 (BEHIND CENTER OF DASH)
SPLICE PACK 210 (RIGHT SIDE OF DASH)
WHT WIRE
YEL WIRE
Go to component -> Cooling fan circuit, without a/c -> RELAY SW RELAY SW SIG SENS LO
