Daewoo Nubira II (1999-2003) parking brake lever switch Wiring diagram
This page shows the only wiring diagram for the component.parking brake lever switch, which is found in the car Daewoo Nubira II (1999-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram parking brake lever switch (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 PNK WIRE
2 1 GROUND VSS A/T
3 10 11 FUEL METER
A/T
A/T ONLY
ABS WARNING LAMP
AIR BAG SYSTEM
AIR BAG WARNING LAMP
ANTI-LOCK BRAKE SYSTEM
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/WHT WIRE
BRAKE FLUID SWITCH
BRN WIRE
BRN/BLK WIRE
BRN/WHT WIRE
CHARGE WARNING LAMP
CLUSTER ILLUMINATION (4 BULBS)
COOLANT TEMPERATURE SENSOR (ON REAR OF CYLINDER HEAD)
DOOR OPEN WARNING LAMP
ENGINE COMPARTMENT FUSE AND RELAY BOX (LEFT SIDE OF ENGINE COMPARTMENT) FUSE 20
ENGINE OIL PRESSURE SWITCH
EXTERIOR LAMP SYSTEM INTERIOR LAMP SYSTEM
FOG LAMP INDICATOR
FUEL METER
FUEL PUMP AND SENDER (TOP OF FUEL TANK)
FUEL WARNING LAMP
FUSE 1
FUSE 29
FUSE 5
GRN WIRE
GRN/WHT WIRE
GROUND
HEADLAMP SYSTEM HEADLAMP SYSTEM
HEADLAMPS SYSTEM ANTI-LOCK BRAKE SYSTEM
HIGH BEAM INDICATOR
HOT AT ALL TIMES
HOT IN ON AND START
HOT WITH LIGHT SWITCH IN PARK OR HEAD
INSTRUMENT CLUSTER
LEFT TURN INDICATOR
LT BLU WIRE
LT GRN WIRE
M/T
M/T ONLY
MALFUNCTION INDICATOR LAMP
OIL PRESSURE WARNING LAMP
ORG/ WIRE
PARKING BRAKE LEVER SWITCH
PARKING BRAKE WARNING LAMP
PASSENGER COMPARTMENT FUSE BOX (BEHIND LEFT SIDE OF DASH)
PNK WIRE
PNK/BLK WIRE
PNK/BLU WIRE
POWERTRAIN CONTROL MODULE (UNDER RIGHT FRONT SEAT)
RIGHT TURN INDICATOR
SEAT BELT WARNING LAMP
SPEEDOMETER
STARTING/CHARGING SYSTEM
TACHOMETER
TEMPERATURE METER
TRUNK LID OPEN WARNING LAMP
VEHICLE SPEED SENSOR (LOWER RIGHT FRONT OF TRANSAXLE)
VEHICLE SPEED SENSOR (VSS) (LOWER RIGHT FRONT OF TRANSAXLE)
VIO WIRE
VSS M/T
WARNING SYSTEM
WHT WIRE
YEL WIRE
Go to component -> Instrument cluster circuit -> PARKING BRAKE LEVER SWITCH
