Daewoo Nubira II (1999-2003) left front door actuator Wiring diagram
This page shows the only wiring diagram for the component.left front door actuator, which is found in the car Daewoo Nubira II (1999-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front door actuator (1 of 1)
3 6 LOCK
ANTI-THEFT SYSTEM
BLK WIRE
BRN WIRE
CENTRAL DOOR LOCK RELAY (BEHIND LEFT KICK PANEL)
ENGINE COMPARTMENT FUSE, RELAY BOX (LEFT SIDE OF ENGINE COMPARTMENT)
EXCEPT STATION WAGON STATION WAGON
FUEL CUT-OFF SWITCH (NEAR CENTER OF DRIVER'S DOOR SILL)
FUSE 28
GRY WIRE
HOT AT ALL TIMES
LEFT FRONT CENTRAL LOCKING, ANTI-THEFT SWITCH
LEFT FRONT DOOR ACTUATOR
LEFT REAR DOOR ACTUATOR
LOCK
LT BLU WIRE
LT BLU/WHT WIRE
ORG/ WIRE
RIGHT FRONT DOOR ACTUATOR
RIGHT REAR DOOR ACTUATOR
TAIL- GATE ACTUATOR (STATION WAGON)
UN LOCK
WHT WIRE
YEL WIRE
Go to component -> Power door locks circuit -> LEFT FRONT DOOR ACTUATOR
