Daewoo Nubira II (1999-2003) blinker unit wiring diagram
This page shows the only wiring diagram for the component.blinker unit, which is found in the car Daewoo Nubira II (1999-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
blinker unit wiring diagram (1 of 1)
2 STEP 1 STEP
ANTI- THEFT CONTROL MODULE
BLINKER UNIT
BLK WIRE
BLU WIRE
BRN WIRE
BRN/WHT WIRE
ENGINE COMPARTMENT FUSE, RELAY BOX (AT LEFT SIDE OF ENGINE COMPARTMENT)
ENGINE COMPARTMENT FUSE, RELAY BOX (AT LEFT SIDE OF ENGINE COMPARTMENT) FUSE 12
FUSE 20
FUSE 21
FUSE 34
GRN WIRE
HATCHBACK/ STATION WAGON
HAZARD SWITCH
HOT AT ALL TIMES
HOT IN ON, START
ILLUMINATION RELAY
INSTRUMENT CLUSTER
LEFT
LEFT FRONT MARKER LAMP
LEFT FRONT POSITION LAMP
LEFT FRONT TURN SIGNAL, POSITION LAMP
LEFT REAR MARKER LAMP
LEFT REAR TAIL LAMP HEADLIGHTS SYSTEM
LEFT TURN SIGNAL INDICATOR
LICENSE PLATE LAMP
LIGHT SWITCH
LT BLU WIRE
NCA WIRE
NOT USED
OFF
OFF ON
ORG/ WIRE
PASSENGER COMPARTMENT FUSE BOX (BEHIND LEFT SIDE OF DASH) FUSE 3
PNK WIRE
RIGHT
RIGHT TURN SIGNAL INDICATOR
SEDAN
SOLID STATE
TURN SIGNAL SWITCH
VIO WIRE
WHT WIRE
Go to component -> Exterior lamps circuit (1 of 2) -> BLINKER UNIT
