Daewoo Nubira II (1999-2003) audio unit Wiring diagram
This page shows the only wiring diagram for the component.audio unit, which is found in the car Daewoo Nubira II (1999-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram audio unit (1 of 1)
AUDIO REMOTE CONTROL SWITCH
AUDIO UNIT
BLK/WHT WIRE
BLU WIRE
BRN WIRE
CONTACT COIL
ENGINE COMPARTMENT FUSE AND RELAY BOX (LEFT SIDE OF ENGINE COMPT)
FUSE 1
FUSE 10
FUSE 9
GLASS AND ROOF ANTENNA
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ACCY AND ON
IGN
ILLUM
LEFT FRONT SPEAKER
LEFT REAR SPEAKER RIGHT REAR SPEAKER
LEFT TWEETER
LT BLU WIRE
ORG/ WIRE
PASSENGER COMPARTMENT FUSE BOX (BEHIND LEFT SIDE OF DASH)
RED WIRE
RIGHT FRONT SPEAKER
RIGHT TWEETER
WHT WIRE
YEL WIRE
