Daewoo Nubira II (1999-2003) anti-theft, door locking switch Wiring diagram
This page shows the only wiring diagram for the component.anti-theft, door locking switch, which is found in the car Daewoo Nubira II (1999-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram anti-theft, door locking switch (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 UNLOCK LOCK
ANTI- THEFT CONTROL MODULE
ANTI-THEFT TEMPER SWITCH (TRUNK)
ANTI-THEFT, DOOR LOCKING SWITCH
B+ LEFT TURN SIG LMP
BLK WIRE
BLU WIRE
BRN WIRE
CENTRAL DOOR LOCKING RELAY (BEHIND LEFT KICK PANEL)
CLOCK ANTI- THEFT INDICATOR
DATA LINK CONNECTOR (DLC) (BEHIND LEFT SIDE OF DASH)
DOOR CONTACT SWITCH
ENGINE COMPARTMENT FUSE, RELAY BOX (AT LEFT SIDE OF ENGINE COMPARTMENT)
FUSE 1
FUSE 13
FUSE 2
FUSE 29
FUSE 35
GRN WIRE
GROUND
HOOD OPEN SWITCH TRUNK LID OPEN SW
HOT AT ALL TIMES
HOT AT ON OR START
INSTRUMENT CLUSTER SYSTEM
LT BLU WIRE
LT BLU/WHT WIRE
LT GRN WIRE
LT LT
NCA WIRE
ORG/ WIRE
PASSENGER COMPARTMENT FUSE BOX (BEHIND LEFT SIDE OF DASH)
PNK PNK WIRE
PNK WIRE
PNK/BLK WIRE
RED WIRE
RIGHT TURN SIG LMP
SERIAL DATA
SIREN
SIREN (AT RIGHT FRONT CORNER OF ENGINE COMPARTMENT)
TRUNK LID OPEN SWITCH HOOD OPEN SWITCH
ULTRASONIC SENSOR (BEHIND LEFT KICK PANEL)
WHT WIRE
YEL WIRE
Go to component -> Anti-theft circuit -> ANTI-THEFT, DOOR LOCKING SWITCH
