Daewoo Nubira II (1999-2003) ambient sensor behind center of front bumper Wiring diagram
This page shows the only wiring diagram for the component.ambient sensor behind center of front bumper, which is found in the car Daewoo Nubira II (1999-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ambient sensor behind center of front bumper (1 of 1)
8 PNK WIRE
A/C COMPRESSOR
A/C COMPRESSOR RELAY
AIR MIX DOOR MOTOR
AMBIENT SENSOR BEHIND CENTER OF FRONT BUMPER
AUTOMATIC TEMPERATURE CONTROL
BLK WIRE
BLOWER MOTOR
BLU WIRE
BLU/BLK WIRE
BRN WIRE
BRN/WHT WIRE
COOLING FAN HIGH RELAY (DIAGRAM 2 OF 2)
DEFOGGER SYSTEM
DIODE
ENGINE COMPARTMENT RELAY & FUSE BOX
ENGINE COMPARTMENT RELAY & FUSE BOX (AT LEFT SIDE OF ENGINE COMPT) FUSE 33
ENGINE CONTROLS SYSTEM (SPEED SIGNAL)
FUSE 10
FUSE 2
FUSE 5
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
HOT IN START, ON
HTR/DEF MOTOR
INTAKE MOTOR
LT BLU WIRE
LT BLU/BLK WIRE
LT GRN/BLK WIRE
MAX HIGH RELAY
MODE MOTOR
ORG/ WIRE
PASSENGER COMPARTMENT FUSE BOX (BEHIND LEFT SIDE OF DASH)
PNK WIRE
PNK/BLK WIRE
PNK/WHT WIRE
POWER TRANSISTOR
RED WIRE
SPLICE PACK 202 (LEFT SIDE OF DASH)
SPLICE PACK 205 (BEHIND CENTER OF DASH)
SPLICE PACK 207 (RIGHT SIDE OF DASH)
SUN SENSOR
VIO WIRE
VIO/WHT WIRE
WATER SENSOR
WHT WIRE
WHT/BLK WIRE
WIPER/ WASHER SYSTEM
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
