Chrysler Voyager IV (2000-2004) (near breakout for intelligent power module Wiring diagram
This page shows the only wiring diagram for the component.(near breakout for intelligent power module, which is found in the car Chrysler Voyager IV (2000-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram (near breakout for intelligent power module (1 of 1)
3.3L/3.8L: (8 GA-
ABOVE STARTER)
AUTOMATIC SHUT DOWN RELAY
BATTERY
BLK WIRE
BRN WIRE
BRN/GRY WIRE
BRN/WHT WIRE
CHARGING SYSTEM IND CNTL VOLTMETER
DIAGNOSTIC JUNCTION PORT
DK GRN WIRE
ENGINE STARTER MOTOR
FUSE 16 FUSE 17
FUSE 24
FUSED B (+)
FUSIBLE LINK 2.4L: (10 GA-
GEN FLD ASD RLY CNTL ASD RLY OUT FUSED B(+) PCI BUS
GENERATOR
HOT AT ALL TIMES
INSTRUMENT CLUSTER
INTEGRATED POWER MODULE (LEFT SIDE OF ENGINE COMPT)
LT BLU WIRE
NCA WIRE
ORG/ WIRE
ORG/RED WIRE
PCI BUS
POWERTRAIN CONTROL MODULE (LEFT SIDE OF ENGINE COMPT)
RED WIRE
WHT WIRE
WHT/VIO WIRE
Go to component -> Charging circuit -> (NEAR BREAKOUT FOR INTELLIGENT POWER MODULE
