Chrysler Voyager IV (2000-2004) fuse 30 fuse 27 Wiring diagram
This page shows the only wiring diagram for the component.fuse 30 fuse 27, which is found in the car Chrysler Voyager IV (2000-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fuse 30 fuse 27 (1 of 1)
A/C COMPRESSOR CLUTCH RELAY
ALL EXCEPT BASE
AUTOMATIC SHUTDOWN RELAY
BODY CONTROL MODULE
BRAKE LAMP SWITCH
BRN WIRE
CONTROLLER ANTILOCK BRAKE
DK GRN WIRE
DRIVER HEATED SEAT MODULE PASSENGER HEATED SEAT MODULE
DRIVER POWER SEAT SWITCH MEMORY SEAT/ MIRROR MODULE
FROM FUSE 20 (DIAGRAM 3 OF 3)
FROM REAR WINDOW DEFOGGER RELAY (DIAGRAM 2 OF 3)
FRONT CONTROL MODULE
FUEL PUMP RELAY
FUSE 14
FUSE 15
FUSE 16
FUSE 17
FUSE 18
FUSE 19
FUSE 20
FUSE 21
FUSE 22
FUSE 26
FUSE 30 FUSE 27
FUSE 31 40
FUSE 32
GRY WIRE
HEADLAMP WASHER RELAY
INTELLIGENT POWER MODULE (LEFT FRONT FENDER SHIELD)
LEFT SLIDING DOOR CONTROL MODULE
LT GRN WIRE
NAME BRAND SPEAKER RELAY
ORG/ WIRE
OVERHEAD CONSOLE
PASSENGER POWER SEAT SWITCH
POWER LIFTGATE MODULE
POWER MIRROR SWITCH
POWER SEAT CIRCUIT BREAKER (UNDER SEAT)
POWERTRAIN CONTROL MODULE
RADIATOR FAN RELAY
RADIO CHOKE
RED WIRE
REMOTE KEYLESS ENTRY MODULE RADIO
RIGHT SLIDING DOOR CONTROL MODULE
SENTRY KEY IMMOBILIZER MODULE AUTO TEMPER- ATURE CONTROL
TO FUSE 21
TRANSMISSION CONTROL MODULE (3.3L/3.8L)
TRANSMISSION CONTROL RELAY
VIO WIRE
W/ DRIVER HEATED SEAT
W/ MEMORY SEAT W/O MEMORY SEAT
W/ PASSENGER HEATED SEAT, POWER SEAT
WHT WIRE
YEL WIRE
