Chrysler Voyager IV (2000-2004) driver seat belt switch line 1 driver seat belt switch line 2 Wiring diagram

1 2 3 BATTERY B+ BATTERY B+ GROUND 17 18 HEADLAMP SW MUX RTN HEADLAMP SW MUX AIRBAG CONTROL MODULE (UNDER RIGHT SIDE OF DASH) BATTERY (B+) BLK/BRN WIRE BLK/TAN WIRE BLK/VIO WIRE BODY CONTROL MODULE (BEHIND LEFT SIDE OF DASH) BRN WIRE BRN/RED WIRE CHIME CHIME DRIVER DIAGNOSTIC JUNCTION PORT (LOWER LEFT OF INSTRUMENT CLUSTER) DRIVER SEAT BELT SW LINE 1 DRIVER SEAT BELT SW LINE 2 DRIVER SEAT BELT SWITCH LINE 1 DRIVER SEAT BELT SWITCH LINE 2 EXCEPT BASE BASE FUSE 14 FUSE 19 FUSE 20 FUSE 24 GROUND GRY WIRE GRY/RED WIRE HEADLAMP SWITCH HOT AT ALL TIMES IGNITION RUN/START IGNITION SW IGNITION SWITCH INSTRUMENT CLUSTER INTEGRATED POWER MODULE (LEFT SIDE OF ENGINE COMPT) KEY-IN SWITCH LEFT FRONT DOOR AJAR SWITCH LEFT FRONT DOOR LOCK MOTOR/AJAR SWITCH LF DOOR AJAR SW SENS LOCK OFF LT GRN/GRY WIRE LT GRN/TAN WIRE ORG/ WIRE PCI BUS PNK WIRE PNK/WHT WIRE RED WIRE RUN WIRE VIO WIRE VIO/BRN WIRE VIO/ORG WIRE VIO/RED WIRE WHT WIRE WHT/BRN WIRE WHT/RED WIRE WHT/VIO WIRE WHT/YEL WIRE
