Chrysler Voyager IV (2000-2004) ash/ receiver lamp feed overhead console Wiring diagram
This page shows the only wiring diagram for the component.ash/ receiver lamp feed overhead console, which is found in the car Chrysler Voyager IV (2000-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ash/ receiver lamp feed overhead console (1 of 1)
A/C HEATER CONTROL
A/T
ASH/ RECEIVER LAMP FEED OVERHEAD CONSOLE
AUTO TEMPERATURE CONTROL
BASE/ HIGHLINE PREMIUM
BLK WIRE
BLK/DK GRN WIRE
BLK/ORG WIRE
BLU WIRE
CENTER DOME LAMP (BASE/ HIGHLINE)
DK GRN WIRE
EX FRONT CONSOLE
EXCEPT BASE
FRONT FLOOR CONSOLE LAMP
FRONT READING LAMPS/ SWITCH
GRY WIRE
HIGH LINE LOW LINE
LEFT MID READING LAMP (PREMIUM/ LUXURY)
LEFT REAR READING LAMP (LUXURY)
LEFT VISOR/ VANITY LAMP (EXCEPT BASE)
LT BLU WIRE
LT LT
M/T
ORG/ WIRE
ORG/DK GRN WIRE
ORG/GRY WIRE
REAR AUTOMATIC TEMPERATURE CONTROL SWITCH
REAR BLOWER REAR CONTROL SWITCH
REAR DOME LAMP (EXCEPT LUXURY)
RIGHT MID READING LAMP (PREMIUM/ LUXURY)
RIGHT REAR READING LAMP (LUXURY)
RIGHT VISOR/ VANITY LAMP (EXCEPT BASE)
W/ FRONT CONSOLE
WHT WIRE
YEL WIRE
YEL/LT BLU WIRE
YEL/ORG WIRE
YEL/WHT WIRE
Go to component -> Interior light circuit (2 of 2) -> ASH/ RECEIVER LAMP FEED OVERHEAD CONSOLE
