Car Wiring Diagrams for Hands free module circuit for Chrysler Town & Country V facelift (2010-2016)

BLK WIRE CAN IHS BUS (-) COMMON AUDIO OUT COMMON AUDIO OUTPUT COMPUTER DATA LINES SYSTEM DATA DK GRN WIRE DK GRN/LT BLU WIRE DK GRN/ORG WIRE DK GRN/WHT WIRE DK GRN/YEL WIRE EXCEPT LIMITED GROUND HANDS FREE MODULE HOT AT ALL TIMES INSIDE REARVIEW MIRROR IOD FD LEFT AUDIO OUT LEFT AUDIO OUTPUT LIMITED LT BLU/DK GRN WIRE LT BLU/WHT WIRE LT GRN/DK BLU WIRE MICROPHONE 2 IN (+) MICROPHONE FEED MICROPHONE IN (-) NCA WIRE ORG/GRY WIRE RADIO (EXCEPT SXT) RED WIRE RIGHT AUDIO OUT RIGHT AUDIO OUTPUT SENSOR GROUND TOTALLY INTEGRATED POWER MODULE USB GND USB PORT USB PWR WHT/GRY WIRE WHT/ORG WIRE
