Power top/sunroof circuit for Chrysler Town & Country V facelift (2010-2016)

Power top/sunroof circuit

Get access

BLK WIRE BLK/LT GRN WIRE CAN-BUS COMPUTER DATA LINES SYSTEM GROUND HOT AT ALL TIMES LT BLU WIRE LT GRN WIRE ORG/ WIRE ORG/LT BLU WIRE ORG/LT GRN WIRE ORG/TAN WIRE ORG/YEL WIRE RED WIRE SUNROOF SUNROOF MODULE (IF EQUIPPED) (SUNROOF ASSEMBLY) SUNROOF PWR CLS (+) SUNROOF PWR OPN (+) SUNROOF PWR PWR OPN CLS (+) (+) SUNROOF SW RTN SUNROOF SWITCH SUNROOF VENT (+) TAN WIRE TOTALLY INTEGRATED POWER MODULE WHT/GRY WIRE WHT/ORG WIRE YEL WIRE
