Passenger power seat circuit for Chrysler Town & Country V facelift (2010-2016)
Passenger power seat circuit
BLK WIRE
BRN WIRE
EXCEPT LIMITED
FRONT PASSENGER VARISTOR
FT BATT FD
FT DN PASS
FT UP PASS
GROUND
HORIZONTAL PASSENGER VARISTOR
HORZ FWD PASS
HORZ RWD PASS
HOT AT ALL TIMES
LIMITED
LT GRN WIRE
LT GRN/BLK WIRE
LT GRN/DK BLU WIRE
LT GRN/DK GRN WIRE
LT GRN/GRY WIRE
LT GRN/LT BLU WIRE
LT GRN/VIO WIRE
LT GRN/WHT WIRE
LT GRN/YEL WIRE
ORG/RED WIRE
PASSENGER SEAT FRONT VERTICAL ADJUSTER MOTOR
PASSENGER SEAT HORIZONTAL ADJUSTER MOTOR
PASSENGER SEAT REAR VERTICAL ADJUSTER MOTOR
PASSENGER SEAT RECLINER ADJUSTER MOTOR
PASSENGER SEAT SWITCH
RCLNR DN PASS
RCLNR UP PASS
REAR PASSENGER VARISTOR
RED WIRE
SEAT CIRCUIT BREAKER
TOTALLY INTEGRATED POWER MODULE
VERT RR DN PASS
VERT RR UP PASS
