Power mirrors circuit for Chrysler Town & Country V facelift (2010-2016)
Power mirrors circuit
BLK WIRE
CAN IHS (-)
COMPUTER DATA LINES SYSTEM
DRIV HEATED MRR FD
DRIV MRR HTR RTN
DRIVER DOOR MODULE
DRIVER HEATER MIRROR
DRIVER MIRROR ADJUSTMENT MOTOR
DRV PWR MRR MTR COM
DRV PWR MRR MTR HORZ
DRV PWR MRR MTR VERT
FSD B(+)
HOT AT ALL TIMES
ORG/ WIRE
PASS HEATED MIRR FD
PASS HEATED MRR FD
PASS MRR HTR RTN
PASS PWR MRR MTR COM
PASS PWR MRR MTR HORZ
PASS PWR MRR MTR VERT
PASSENGER DOOR MODULE
PASSENGER FRONT DOOR)
PASSENGER HEATER MIRROR
PASSENGER MIRROR ADJUSTMENT MOTOR
RED WIRE
RED/LT BLU WIRE
RED/LT GRN WIRE
TOTALLY INTEGRATED POWER MODULE
WHT WIRE
WHT/GRY WIRE
WHT/ORG WIRE
